drylin linear technology

Profile guides
Offer a wide range of applications as over 50 different profiles, linear plain bearings and carriages can be combined to create a ready-to-install system or a modular system.

Low-profile guide systems
drylin N low-profile guide systems are characterised by system heights of 6 to 12mm. This makes the aluminium rails with plastic carriages particularly suitable for applications in small installation spaces.

Rail guides

Sliding instead of rolling - the drylin T linear rail guide is based on this principle. The connection and drilling dimensions of the drylin linear rails and linear carriages are identical to the commercially available recirculating ball bearing versions.

Shaft guides
drylin R linear bearings utilise special wear-resistant polymers that have been specially developed for the requirements of linear technology. The dimensions are compatible with standard ball bushings.

Square guides

drylin Q square guides enable an extremely flexible design. Various pillow block versions are available, including solid plastic bearings and adjustable complete housings with and without manual clamp, which can be customised.

Telescopic rails

The telescopic rails consist of anodised aluminium guide rails and a sliding element made of iglidur high-performance plastics. This combination enables quiet, hygienic and dry-operating movement of the telescopic rails.

Pre-load prism slides
The pre-load prism slides offer a choice of four pre-load classes and are therefore suitable for a wide range of applications. They can also be used in hygienic environments. The screw connection can be made from below or via a threaded pin, which enables flexible installation.

Roller guides
Our roller bearings are cost-effective die-cast zinc housings. These enable up to 70% smoother operation and easy, energy-efficient adjustment. They are also lubrication-free and quiet.

Measuring systems

Suitable measuring systems have been developed for every application based on the profile, square and low-profile guide system. Whether for particularly flat installation spaces, on a square profile or for the standard on a drylin W rail.
